1. Product parameters

2. Features:

Generalization: it covers the power range of 16-24hp. Different compressors can easily configure parameters by dialing codes.

3. High reliability:

① Dual on-off topology: easy to achieve standby power consumption < 5W, meeting customers' energy saving needs and extending the service life of capacitors;

② High pressure hardware protection of compressor discharge: the compressor discharge pressure is linked with the bus relay to ensure the safety of the unit under extreme conditions;

③ Three phase unbalance treatment mechanism: ensure reliable operation even under poor power grid quality conditions and no attenuation of service life;

④ Pollution level III + full coating: ensure the reliable operation of products in harsh pollution environment;

⑤ Double 85 and strict test: comprehensive multi-dimensional (voltage, temperature and load) rigorous test to ensure the normal operation of the product under extreme conditions;

⑥ Professional PCBA OEM: ensure the production quality of delivered products is more reliable.
